Dip switch DS1 positions information
No. OFF ON Signal
All switches are
set to OFF as the
default.
1 OPEN
120
Ω
Standard serial terminator changeover
2
V1
I1
AI1
voltage, current changeover
3 V2 I2 AI2 voltage, current changeover
4 PS03 PULSE
Sequence output, pulse train output
changeover
Jumper W1, W2, W3, W4 position information
No. 1 2 Signal
All jumpers are
set to 1 as the
default.
W1 SINK SOURCE PSI1 6 sink ! source changeovers
W2 SINK SOURCE PSI7 sink ! source changeover
W3 voltage current AO1 voltage, current changeover
W4 voltage current AO2 voltage, current changeover
