6-4 List of key parameters
Listed here are the key parameters used to set up the drive to meet the requirements of most
applications. Typically, only a few of these parameters are changed from their default values. Please
refer to the detail Instruction Manual for the complete parameter listing and Fault Codes.
No.
D00-D30: Monitor Group Read-only Drive Monitor parameters
D00-0 Output Frequency Output Frequency being applied to the AC motor in Hz.
D00-4 Motor Speed Speed of the motor in RPM, revolutions per minute.
D01-0 Set Frequency The active speed reference is displayed
D02-0 Output Current Current that is being supplied to the motor in Amps
D02-1 Output Current Current that is being supplied to the motor in % of the motor’s
Full Load Amp (FLA) rating
D02-4 Heatsink temperature Displays the heat sink temperature in °C
D03-0 DC voltage Displays the voltage of the DC link circuit in the main circuit
D03-1 Output Voltage Calculated output voltage
D03-2 Output power Displays inverter’s output power
D20-0 Fault history monitor Provides fault history for last 4 faults and information of 5
important parameters at the time of fault.
D20-2 Non-default parameter list This parameter is used to see the non-default parameters list
and their value.
A00-0 Local Frequency Setting Setting the motor speed with the keypad
A00-1 Jog Frequency Frequency run when Jog input is used
A01-0 Acceleration Time – 1 Time to accelerate from Zero to Max Speed in seconds
A01-1 Deceleration Time – 1 Time to decelerate from Max Speed to Zero in seconds
A05-0
Parameter B and C
extended setting
Allows to see extended functions in Mode B and C
A05-1
Parameter B and C
software option function
Allows to see software option functions in Mode B and C
A05-2
Parameter B and C
hardware option function
Allows to see hardware option functions in Mode B and C
B00-0 ~
B00-7
Motor Parameters Key motor values that must be programmed at start-up
B00-4 Maximum Frequency
Maximum Frequency (Speed) the motor will run. Speed at
10VDC and 20mA for analog inputs
B07-1 Lower limit (Minimum
Frequency) for v/f mode
Minimum Frequency (Speed) the motor will run, Speed at 0VDC
and 4mA for analog inputs.
B19-0 Automatic tuning selection Used to select the type of auto-
tuning in v/f and vector control
mode
B43-0 ~
B43-A
PID Parameters PID Set point Controller functions
C00-0 Run command, Maintained
Start/Stop
Selects 2 or 3 wire start/stop control
C00-1 Stop Mode Selects Ramp to stop or Coast to stop
C00-3 Emergency stop (EMS)
input logic
Selects the logic for the emergency stop input
C00-4 Emergency stop (EMS)
mode
Selects the stop method for the emergency stop input
C03 ~ PSI 1-6 Digital Inputs Selects the function of the Digital Inputs (Prog. Seq. Inputs)
