B00-2
Motor rated output
(V/f control)
Inverte
r rating
(kW)
0.10 750.00 The motor rated output at the base frequency is set.
B00-3 Motor rated output
(V/f control)
Vac 230.
or
400.
(V)
39 480 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting value
depends on the 400V, 500V or 600V Series model.
B00-4
Max. frequency
(Fmax)
(V/f control)
50.00
(Hz)
Fbas
e or
3.00
Fbase
*7 or
440.0
0
When "B00-1" is a value other than 0, this will be
rewritten with the data set in the simple setting.
B00-5 Base frequency
(Fbase)
(V/f control)
50.00
(Hz)
Fmax/
7 or
1.00
Fmax
or
440.00
B00-6
Motor rated
current
(V/f control)
Invert
er
rating
(A)
Invert
er
rating
× 0.3
Inverte
r rating
This is the reference value for the over current limit,
OLT, current % display, analog input and output.
B17-0
V/f middle point
Setting-Freq 1
0.00 0.00
Max
freque
ncy
=3 to 5% of motor frequency
B17-1
V/f middle point
Setting-Volt 1
0.0% 0.0 200 =9 to 12%, voltage
B17-2
V/f middle point
Setting-Freq 2
0.00 0.00
Max
freque
ncy
=5 to 8% of motor frequency
B17-3
V/f middle point
Setting-Volt 2
0.0% 0.0 200 =12 to 16%, voltage
B17-B
V/f middle point
use selection
1 2 1
= 2, function valid
Note: V/F Custom curve must be required for starting
torque when load is present on carrier.
C03-d
AFS1, Speed
setting 1
16 -11 16 = 0
C04-0
PROG 0 -11 16 =16 Multi speed function is valid
C04-2
S0, Prog. speed
selection
0 -11 16 = Select PSI for first speed
C04-3
S1, Prog. speed
selection
0 -11 16 = Select PSI for second speed
C04-4
S2, Prog. speed
selection
0 -11 16 = Select PSI for second speed
CAUTION
• Don’t enable speed search function
• Don’t enable auto restart function
Note:
Speed Reference Selection: Enable below require parameter as per source of frequency reference
• A00-0 – Local Set Frequency (Keypad of Axpert-Eazy)
• C03-D or C03-E – Frequency Reference Input (i.e. 0~10V, 4~20mA etc.)
I/O's Requirements: Enable below parameter as per requirement.
• C03-0 to C03-C and C13-0 to C13-6 for Digital I/O and C12-0 to C12-F and C14-0 to C14-B for
Analog I/O.
