22
Pedal Leveler Pulley
Install the pedal leveler pulley into the front hole of the black basket plate on
the rear frame. Insert the pedal leveler cord through each pedal and tie a knot
in one end of the cord to hold in place.
Basket
Start by removing the 25mm Allen bolts, washers and basket bracket from the
back of the black plate at rear of bike.
1. Place the basket on the plate and
align the holes. Insert the Phillips
head screw in one of the center
holes, but do not fully tighten until
the other bolts are installed.
2. Place the chrome basket bracket in
the basket so that it aligns with the
two holes that you removed the
25mm Allen bolts from.
3. Put the two Allen bolts through the metal basket brace and rear frame, and
tighten with a 6 mm Allen wrench. Be careful to get the crews threaded
correctly.
