Steering Pin
If needed, insert the steering pin into the front fork tube from the side. Attach
the adhesive hook strip to the frame to
keep the pin secure from loss. Three
steering positions are available:
• Top position: Locks steering straight.
• Lower position: Limits steering to 20
degrees in either direction.
• No pin: Free steering.
Jiggle the front wheel assembly as you
push the pin into the hole and through
the other side of the fork tube. The pin should insert all the way to the split ring
to be correctly seated.
Wheel Reflectors
To install the wheel reflectors, place them in an area on the rim behind a single
spoke with two spokes on the opposite
side. Align the spoke with the slot in the
reflector and insert the reflector holding
pin with the slotted end going over the
spoke into the hole in the reflector.
Press firmly until you hear it click into
place – or use a flat blade screwdriver
and turn ¼ to lock.
