Fitting Amtryke for Rider
The ProSeries models 1416, 1420, and 1420-XL can be adapted to different
types of riders. See the information below for quick reference on rider size
requirements:
Follow these instruction to adjust the tryke for the rider:
1. Engage the parking brake.
2. Adjust the seat height. Start with the seat post in the lowest position and
adjust upward if needed. Tighten the seat securing knob.
3. Slide the seat post bracket forward/back. Rider’s knees should be slightly
bent when legs are extended. Tighten the levers securely.
4. Adjust the seat back and lateral supports to suit the rider. Tighten the levers
securely.
5. Adjust the handlebar (up/down, forward/back).
6. Adjust the pedals to fit the rider’s feet and secure the straps.
7. Adjust the lateral support, chest straps and seat belt.
If you need further adjustments, see Optional Accessories on the next page for
different options.
1416
Rider’s height: Max. 60 inches
Arm length 14-22 inches
Leg length 24-32 inches
Maximum weight: 175lbs
1420 and 1420-XL*
Rider’s height: Max. 72 inches 76*
Arm length 18-28 inches 20-32*
Leg length 27-35 inches 28-43*
Maximum weight: 250lbs & 275lbs*
NOTE: You may need assistance while fitting the tryke.
