AmTryke 1416 - Seat

18
When the stem is securely tightened, remove the two 6 mm Allen bolts from
the handlebar clamp (see image below). Insert the handlebar with the quick
release levers oriented up and replace the handlebar clamp. Tighten the bolts.
Seat
Seat assembly consists of a seat post bracket, saddle seat and seat post. Start
by installing the red seat post bracket onto the rear frame:
Front fork tube
Handlebar stem
DO NOT EXCEED THE MAX. HEIGHT LINE
Handlebar clamp
Handlebar stem
Allen bolts
Handlebar
clamp
Handlebar
clamp
Quick
release
lever
Hash
marks
TIP: Use the quick release wrench to
easily tighten quick release levers.
