AMW T342 - Page 25

25
If your TV or display device supports a Component Video connection, connect
the Component Video Output cable (not included) from the rear panel of the
DVD player as shown in the above illustration.
Component Video Output
Getting Started
T342 DVD Player (back)
Television
