Integrated Master – NetLinx® Programming
194
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
VIDIN_HDCP
Sets the video input HDCP
compliance setting of the
specified video input port.
NOTE: VIDIN_HDCP commands for Solecis switchers must be sent directly to the Solecis unit, not
sent via the 5002 device.
When VIDIN_HDCP is disabled, the addressed video input will appear to any source as not being HDCP
compliant.
For computer sources that encrypt all video when connected to an HDCP compliant display, disabling
HDCP compliance on the input will cause the computer to send non-encrypted video which can then be
routed to non-compliant displays and video conferencing systems.
NOTE: It may be necessary to disconnect and re-connect PC sources after changing this setting.
IMPORTANT: Disabling HDCP compliance for sources that do not support non-compliant displays
(such as DVD and Blu-Ray players) is not recommended and may affect the source’s ability to
send video.
Syntax:
SEND_COMMAND <DEV>,"'VIDIN_HDCP-<option>'"
Variables:
option = ENABLE, DISABLE (default = ENABLE)
Example:
SEND_COMMAND VIDEO_INPUT_1,"'VIDIN_HDCP-ENABLE'"
Enables the HDCP compliance of video input port #1.
?HDCPSTATUS
Request the video input
encryption status addressed by
the D:P:S
Syntax:
SEND_COMMAND <DEV>,"'?HDCPSTATUS'"
Example:
SEND_COMMAND VIDEO_INPUT_1,"'?HDCPSTATUS'"
Returns a COMMAND string of the form: HDCPSTATUS-<status string>
status string = ENABLE, DISABLE, or ERROR.
?VIDIN_NAME
Requests the input name of the
specified video port.
Syntax:
SEND_COMMAND <DEV>,"'?VIDIN_NAME'"
Example:
SEND_COMMAND VIDEO_INPUT_1,"'?VIDIN_NAME'"
Returns a COMMAND string of the form: VIDIN_NAME-<name>
VIDIN_NAME
Sets the name of the specified
port to <name>.
NOTE: The Input name may be
changed using either the
VIDIN_NAME or AUDIN_NAME
command. Both commands are
used to change the same name
attribute and do not create
separate names for video or
audio.
The <name> length is limited to 31 characters. Specifying a longer name will result in truncation to
the 31 character length limit.
Valid characters are:
• a-z (lower case letters)
• A-Z (upper case letters)
• 0-9 (numeric)
• #.-_=+ (special characters hash, period, dash, underscore, equal, plus <space>
[space characters at the beginning of a name are truncated])
Syntax:
SEND_COMMAND <DEV>,"'VIDIN_NAME-<name>'"
Variables:
name = A string name (e.g., PC 1)
Example:
SEND_COMMAND VIDEO_INPUT_1,"'VIDIN_NAME-MyPC'"
Sets the name of input port (#1 based on D:P:S) to MyPC. This is used for the On Screen Display
feature.
?VIDIN_PREF_EDID
Requests the preferred
resolution of the EDID source
being mirrored by the specified
video port.
Syntax:
SEND_COMMAND <DEV>,“'?VIDIN_PREF_EDID'”
Example:
SEND_COMMAND VIDEO_INPUT_1,“'?VIDIN_PREF_EDID'”
Returns a COMMAND string of the form: VIDIN_PREF_EDID-<resolution>
VIDIN_PREF_EDID
Sets the preferred resolution for
the EDID source to mirror in the
specified video input port
IMPORTANT: You can only set the preferred resolution if you use the VIDIN_EDID command to set
the EDID source to All Resolutions, Wide-screen, Full-screen, or 4K.
Syntax:
SEND_COMMAND <DEV>,“'VIDIN_PREF_EDID-<resolution>'”
Example:
SEND_COMMAND VIDEO_INPUT_1,“'VIDIN_PREF_EDID-1280x1024,60'”
?VIDIN_RES_REF
Requests the resolution of the
video input port addressed by
the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'?VIDIN_RES_REF'"
Example:
SEND_COMMAND VIDEO_INPUT_1,"'?VIDIN_RES_REF'"
Returns a COMMAND string of the form: VIDIN_RES_REF-<h>x<v>,<rate>
Standard Input SEND_COMMANDs
