Product Overview and General Specifications
11
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Product Overview and General Specifications
Applicability Notice
The information in this manual applies to the following Enova DGX 100 Series Digital Media Switcher enclosures, plus input, output,
and expansion boards, which can be ordered to create custom systems. All of the boards listed in this Applicability Notice are
compatible with any of the Enova DGX enclosures listed below.
NOTE: AMX reserves the right to modify its products and their specifications without notice.
NOTE: All Enova DGX Switchers ship with a standard front control panel.
Enova DGX 800 Enclosure (4 RU)
Enova DGX 1600 Enclosure (4 RU)
Enova DGX 3200 Enclosure (6 RU)
Enova DGX 6400 Enclosure (13 RU)
Enova DGX Digital Media Switchers Standard Video Input and Output Boards
Enova DGX 100 Series Switchers currently support four standard Enova DGX input and output board types: HDMI, DVI, DXLink
Twisted Pair, and DXLink Fiber Boards. Each board fills one of the standard I/O board slots and has four connectors. Within a
system, a source device connected to any of the input boards can be routed to any destination device connected to any of the
output boards (check the board chapters for important signal information when routing between board types).
For general board information, see page 20 and page 45.
For specific board information, see the applicable board chapter in this manual.
Enova DGX HDMI Boards (page 62)
Enova DGX DVI Boards (page 74)
Enova DGX DXLink Twisted Pair Boards* (page 82)
* Enova DXLink Twisted Pair Boards must be used in conjunction with DXLink Twisted Pair Transmitters and Receivers or other AMX
DXLink signal management solutions. For model numbers of compatible Transmitters and Receivers, see page 83. For system setup
information, see page 87.
IMPORTANT: Before connecting a Solecis Digital Switcher to a DXLink Twisted Pair Input Board in an Enova DGX 100 Series Digital
Media Switcher, both the Solecis unit and all DXLink Twisted Pair boards must be upgraded with the latest available firmware versions.
Solecis units must be upgraded before connecting a unit to an upgraded input board.
Configuration Part # Model
8x8 Video and up to 16x16 Audio with Audio Switching Boards FG1061-08 DGX800-ENC (ENOVA DGX 800 ENC)
Configuration Part # Model
16x16 Video and up to 24x24 Audio with Audio Switching Boards FG1061-16 DGX1600-ENC (ENOVA DGX 1600 ENC)
Configuration Part # Model
32x32 Video and up to 40x40 Audio with Audio Switching Boards FG1061-32 DGX3200-ENC (ENOVA DGX 3200 ENC)
Configuration Part # Model
64x64 Video and up to 80x80 Audio with Audio Switching Boards FG1061-64 DGX6400-ENC (ENOVA DGX 6400 ENC)
Type Part # Model
HDMI Input FG1058-540 DGX-I-HDMI
4K HDMI Input FG1061-540 DGX-I-HDMI-4K
HDMI Output FG1058-550 DGX-O-HDMI
Type Part # Model
DVI Input FG1058-600 DGX-I-DVI
DVI Output FG1058-610 DGX-O-DVI
Type Part # Model
DXLink Twisted Pair Input FG1058-570 DGX-I-DXL
DXLink Twisted Pair Output FG1058-580 DGX-O-DXL
