Enova DGX DXLink™ Twisted Pair Boards
83
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
InstaGate Pro
®
Technology
DXLink Boards meet HDCP standards and support InstaGate Pro Technology. For information on HDCP functionality for
DXLink boards, see “HDCP Support on Enova DGX Switchers” on page 70.
DXLink Boards provide EDID emulation support with plug-and-play information provided by the Enova DGX Switcher.
DXLink input and output connectors incorporate HDMI Technology, are HDCP 1.4 compatible, and feature InstaGate Pro
Technology* for low-latency switching of HDCP protected content and support computer video up to 1920x1200 and HDTV
up to 1080p. The DXLink connectors also support embedded audio, both linear PCM (stereo audio) and non-linear PCM
(Dolby Digital, Dolby TrueHD, DTS, etc.).
* InstaGate Pro Technology eliminates HDCP latency and interruptions on all displays in a system. (These conditions are typically
experienced when HDCP authenticates HDMI source and destination devices.) Key limitations on source devices are also eliminated
by allowing them to see only a single sink key from the DXLink Input Board’s input connection. With InstaGate Pro Technology,
when a source requires HDCP encrypted content, the inputs and compliant downstream devices are automatically authenticated.
Enova DGX DXLink™ Twisted Pair Boards – Specifications
Applies to input board FG1058-570 (DGX-I-DXL) and output board FG1058-580 (DGX-O-DXL).
NOTE: Compatibility is available between DXLink Twisted Pair equipment and DXLink Twisted Pair 4K equipment (see the “DXLink
Compatibility” Appendix in the “DXLink Twisted Pair 4K Transmitters and Receivers Hardware Reference Manual” at www.amx.com).
Compatible AMX DXLink™ Twisted Pair Transmitters and Receiver:
DXLink Multi-Format TX: FG1010-310 (DX-TX)
DXLink Multi-Format Wallplate TX: FG1010-320-BL (DX-TX-WP-BL)*
DXLink Multi-Format Wallplate TX: FG1010-320-WH (DX-TX-WP-WH)*
DXLink Multi-Format Decor Style Wallplate TX (US): FG1010-325-BL (DX-TX-DWP-BL)*
DXLink Multi-Format Decor Style Wallplate TX (US): FG1010-325-WH (DX-TX-DWP-WH)*
DXLink HDMI RX: FG1010-500 (DX-RX)**
* These Transmitters are available with a black front (BL) or a white front (WH).
** The Receiver features SmartScale Technology and is also compatible with the DXLink output connections on Enova DVX
Solutions.
Compatible AMX Solecis Digital Switchers (1 Output per Switcher):
Solecis 4x1 HDMI Digital Switcher with DXLink Output
Solecis 5x1 Multi-Format Digital Switcher with DXLink Output
Solecis 8x1 HDMI Digital Switcher with DXLink Output
IMPORTANT: DXLink twisted pair cable runs for DXLink equipment shall only be run within a common building. “Common building” is
defined as: Where the walls of the structure(s) are physically connected and the structure(s) share a single ground reference.
