Enova DGX DXLink Twisted Pair Board Specifications
Parameter Value
Compatible AMX DXLink™
Products
Multi-Format TX, Multi-Format Wallplate TX, Decor Wallplate TX, and DXLink RX; and other AMX
DXLink signal management products
Compatible Formats HDMI video, audio, Ethernet, USB (HID), power, and control
Signal Type Support DXLink Twisted Pair
Transport Layer Throughput (max.) 10.2 Gbps
Video Data Rate (max.) 4.95 Gbps / 6.75 Gbps^
Video Pixel Clock (max.) 165 MHz / 225 MHz^
Progressive Resolution Support 480p up to 1920x1200,60Hz
Interlaced Resolution Support* 480i, 576i, 1080i
Deep Color Support 24-bit, 30-bit^, 36-bit^
Color Space Support RGB 4:4:4
YCbCr^^ 4:4:4 and 4:2:2
3D Format Support Yes (HDMI primary formats), when used with DXLink Output Boards and the RX Scaler is in Bypass
mode
• Frame Packing 1080p up to 24 Hz
• Frame Packing 720p up to 50/60 Hz
• Frame Packing 1080i up to 50/60 Hz
• Top-Bottom 1080p up to 24 Hz
• Top-Bottom 720p up to 50/60 Hz
• Side-by-Side Half 1080i up to 50/60 Hz
Audio Format Support Dolby TrueHD, Dolby Digital*, DTS-HD Master Audio, DTS*, 2 CH L-PCM, 6 CH L-PCM, 8 CH L-PCM
Audio Resolution 16 bit to 24 bit
Audio Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Local Audio Support Yes, insertion and/or extraction of 2 CH L-PCM selectable by channel
EDID Support • EDID provided by Enova DGX Digital Media Switcher to the digital (HDMI) input on the DXLink
Multi-Format TX
• EDID is user re-programmable
HDCP Support Yes, full matrix HDCP support (includes any input to any or all outputs)
• Key Management System
• AMX HDCP InstaGate Pro® Technology
• Key support up to 16 destinations per output, independent of source device
CEC Support None
ICSP, TCP/IP, USB, IR, and
Control Management
Control Distribution is managed by the Enova DGX Digital Media Switcher on-board NetLinx NX
Master and Ethernet Switch
USB (HID) Transport Use the Enova DGX Digital Media Switcher in conjunction with DXLink Transmitters and Receivers
(twisted pair and/or fiber), connect a DXLink Transmitter to a PC and a DXLink Receiver to a
keyboard and mouse, the system then emulates commands from the receiver back to the PC.^^^
DXLink Twisted Pair Power DXLink Twisted Pair Transmitters and Receivers can have power supplied over twisted pair cable
when connected to a DXLink Input or Output Board on the Enova DGX Digital Media Switcher
Input Board Propagation Delay 5 μs
Output Board Propagation Delay 5 μs
Audio Switching Board Support Yes, Supports break-away audio switching of 2 CH L-PCM for all channels and downmix Dolby
True-HD, Dolby Digital, DTS-HD or DTS for one input channel
Connectors 4 RJ-45 ports
Twisted Pair Cable Type Shielded Cat6, Cat6A, Cat7**
Twisted Pair Cable Length Up to 328 ft. (100 m)**
Important Notice DXLink twisted pair cable runs for DXLink equipment shall only be run within a common building.
A “Common building” is defined as: Where the walls of the structure(s) are physically
connected and the structure(s) share a single ground reference.
