Modero S Series Touch Panels - Installation & Hardware Reference Manual
Touch Panel Aspect Ratio
While the touch panel screen physical dimensions fall between 16:9 and 16:10, any incoming video stream can be scaled to 16:9 if
needed. This may lead to some letter boxing around the video in some cases.
MSD-431-L Specif ications (Cont.)
COMMUNICATIONS • Ethernet: 10/100 Auto MDI-X port, RJ-45 connector. Supported IP and IP-based protocols: UCP, TCP,
ICMP, ICSP, IGMP, DHCP, Telnet, FTP, DNS, RFB (for VNC), HTTP
• USB: (1) USB host 2.0, Type A port: firmware upgrade, touch panel file transfer, JPEG image viewer,
HID peripherals
• Bluetooth®: Mouse/Keyboard: HID Profile v1.1, requires MXA-BT, Bluetooth USB Adapter for Modero
X/S Series Touch Panels (FG5968-19) and MXA-HST, Bluetooth Handset for Modero X/S Touch Panels
(FG5968-17)
VIDEO Supported Video Codecs: MJPEG up to 720p at 25 fps (decode only)
AUDIO • Microphone: -42 dB ±3 dB sensitivity FET microphone
• Speakers: 4 ohm, 1.5 Watt, 500 Hz cutoff frequency
• Supported Audio Codecs:
MP2 Layer I and II, MP3 (8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz,
48 kHz)
AAC-LC (8 kHz, 96 kHz)
G.711 with μLaw (VoIP encode/decode at 8 kHz)
• File Formats: WAV, MP3 (as part of touch panel file only - no USB storage)
• Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG)
GRAPHICS ENGINE AMX G4: AMX's exclusive, powerful G4 graphics engine – the driving force behind the advanced graphics
and image processing capability on a variety of AMX Touch Panels and other devices (see TPD4
Operations Guide for more information)
EMBEDDED APPLICATIONS • Remote Management: VNC Server, G4 Web Control, AMX Resource Management Suite
• Video Conferencing: Panel-to-panel and video chat (the MSD-431 receives video and returns audio)
• Audio Conferencing: Audio (Full Duplex Intercom)
FRONT PANEL COMPONENTS • Sleep Button: Sleep button to activate sleep mode and power off. Also provides access to setup pages
(can be disabled)
• Programmable Red/Green LEDs: Programmable red/green LED in the front, left and right sides of the
panel, LEDs are beautifully recessed and nearly invisible when not lit
CONNECTIONS • Ethernet: 10/100 Auto MDI-X port, RJ-45 connector
• USB: (1) USB host 2.0, type A port
• Power: PoE (Power over Ethernet), 802.3af, class 3
ENVIRONMENTAL • Temperature (Operating): 32° F to 104° F (0° C to 40° C)
• Temperature (Storage): 4° F to 140° F (-20° C to 60° C)
• Humidity (Operating): 20% to 85% RH
• Humidity (Storage): 5% to 85% RH
• Power ("Heat") Dissipation:
On: 13.6 BTU/hr
Standby: 10.9 BTU/hr
INCLUDED ACCESSORIES • Installation Template 4.3" S Series (68-5968-02)
OPTIONAL ACCESSORIES • MSA-MMK-43, Multi Mount Kit, 4.3" Modero S Wall Mount (FG2265-13)
• MXA-MP, Modero X/S Series Multi Preview (FG5968-20)
• MXA-MPL, Modero X/S Series Multi Preview Live (FG5968-10)
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)
• MXA-BT, Bluetooth USB Adapter for Modero X/S Series Touch Panels (FG5968-19)
• MXA-HST, Bluetooth Handset for Modero X/S Series Touch Panels (FG5968-17)
• CB-MSA-43, Rough-In Box and Cover Plate for the 4.3" Wall Mount Modero S Series Touch Panel
(FG2265-10)
• MXA-CLK, Modero X/S Series Screen Cleaning Kit (FG5968-16)
• MXA-USB-C, USB Port Covers for the Modero X/S Series Touch Panels (FG5968-18)
