AMYET S6 - Battery Level Display

AMYET S6 E-BIKE
10
5.Boost Gear Selection
+
Short press key to switch the electric vehicle power assist gear, thus changing the
motor output power.
6.Battery Level Display
7.Error icon display
The icon is always on to show the pure electric and power assisted modes, without this
icon it is pure electric mode, and with this icon blinking it is pure power assisted mode.
Battery percentage display, when the battery is fully charged the meter will show 100%
and the indicator bar is fully lit (red bar + green bar), when the battery is undervoltage the
battery outer bezel blinks. suggesting that it needs to be recharged immediatelv.
When there is a malfunction in the electric control system of the electric vehicle, the
instrument will automatically display an error code, see the following for the detailed
definition of the error code.
Figure 5 Gear switching display interface
Figure 6 Battery level display screen
