AMYET S6 - Display and Setting; Specification

AMYET S6 E-BIKE
7
DISPLAY AND SETTING
1.View Sth From The Outside
2.Appearance Size(unit:mm)
SPECIFICATION
APPEARANCE AND PARAMETERS
Rated operating power of the instrument: 15mA
Maximum operating current of the instrument 30mA
Shutdown leakage current: <1uA
Power supply to the controller: 50mA
Working temperature: -20～60°C
Storage humidity: -30 to 70°C
Figure 1 Physical diagram of the meter and keypad
Picture 2.1 SX985 Instrument Front
View Dimensions
Figure 2.2 SX985 Instrument Side View
Dimension Drawing
