AMYET S6 - Install the Front Wheel

AMYET S6 E-BIKE
5
2.Install the handlebar
A.Use the hex wrench to remove the bolts from the handlebar clamp.
B. Once the clamp is open, place the lower crossbar of the handlebar in the groove of the
top crown.
C. Loosely tighten the handlebar clamp with the hex wrench, and adjust the angle of the
handlebar to rider’s comfort.
D. Cross-tighten the handlebar clamp from corner-to-corner making sure the clamp is tight
and handlebars do not move.
3.Install the front wheel
A.Lift the body of the electric vehicle.
B.Then the brake disc stuck in the position of the brake.
C.Pay attention to the sequence of gaskets,front fork,washer,nut.
D.Adjust the position with a wrench to tighten the nut.
E.Put on the nut protective cap.
F.Connect the front wheel motor line, pay attention to the direction of the motor line
should be aligned with the insert.
G.Then clockwise tighten the screws.
A B C D
A B C D
