ADE9000 Technical Reference Manual UG-1098
Rev. 0 | Page 5 of 86
The ADC data in the waveform buffer is stored as 32-bit data by
shifting left by 4 bits and sign extending, as shown in Table 3.
Table 3. 32-Bit ADC Data Format
Bits[31:28] Bits[27:4] Bits[3:0]
SE ADC_DATA[23:0] 0000
The expected output code in the waveform buffer from the sinc
filter when input is at 1 V peak is 67,107,786 (decimal). The
expected output code in the waveform buffer from the decimator
filter when input is at 1 V peak is 74,518,668. See the Waveform
Buffer section for more information.
VOLTAGE REFERENCE
The ADE9000 supports a 1.25 V internal reference. An external
reference can be connected between the REFIN and REFGND
pins. When using an external voltage reference, set the
EXT_REF bit of the CONFIG1 register, which disables the
internal reference buffer.
