UG-1098 ADE9000 Technical Reference Manual
Rev. 0 | Page 64 of 86
Address Name Description Reset Access
0x685
AVA_2
SPI burst read accessible. Registers organized by phase. See AVA.
0x00000000
R/W
0x686 AVAR_2 SPI burst read accessible. Registers organized by phase. See AVAR. 0x00000000 R/W
0x687 AFVAR_2 SPI burst read accessible. Registers organized by phase. See AFVAR. 0x00000000 R/W
0x688 APF_2 SPI burst read accessible. Registers organized by phase. See APF. 0x00000000 R/W
0x689 AVTHD_2 SPI burst read accessible. Registers organized by phase. See AVTHD. 0x00000000 R/W
0x68A AITHD_2 SPI burst read accessible. Registers organized by phase. See AITHD. 0x00000000 R/W
0x68B AFWATT_2 SPI burst read accessible. Registers organized by phase. See AFWATT. 0x00000000 R/W
0x68C AFVA_2 SPI burst read accessible. Registers organized by phase. See AFVA. 0x00000000 R/W
0x68D AFIRMS_2 SPI burst read accessible. Registers organized by phase. See AFIRMS. 0x00000000 R/W
0x68E AFVRMS_2 SPI burst read accessible. Registers organized by phase. See AFVRMS. 0x00000000 R/W
0x68F AIRMSONE_2 SPI burst read accessible. Registers organized by phase. See AIRMSONE. 0x00000000 R/W
0x690 AVRMSONE_2 SPI burst read accessible. Registers organized by phase. See AVRMSONE. 0x00000000 R/W
0x691 AIRMS1012_2 SPI burst read accessible. Registers organized by phase. See AIRMS1012. 0x00000000 R/W
0x692 AVRMS1012_2 SPI burst read accessible. Registers organized by phase. See AVRMS1012. 0x00000000 R/W
0x693 BV_PCF_2 SPI burst read accessible. Registers organized by phase. See BV_PCF. 0x00000000 R/W
0x694 BI_PCF_2 SPI burst read accessible. Registers organized by phase. See BI_PCF. 0x00000000 R/W
0x695 BIRMS_2 SPI burst read accessible. Registers organized by phase. See BIRMS. 0x00000000 R/W
0x696 BVRMS_2 SPI burst read accessible. Registers organized by phase. See BVRMS. 0x00000000 R/W
0x697 BWAT T_2 SPI burst read accessible. Registers organized by phase. See BWATT. 0x00000000 R/W
0x698 BVA_2 SPI burst read accessible. Registers organized by phase. See BVA. 0x00000000 R/W
0x699 BVAR_2 SPI burst read accessible. Registers organized by phase. See BVAR. 0x00000000 R/W
0x69A BFVAR_2 SPI burst read accessible. Registers organized by phase. See BFVAR. 0x00000000 R/W
0x69B BPF_2 SPI burst read accessible. Registers organized by phase. See BPF. 0x00000000 R/W
0x69C BVTHD_2 SPI burst read accessible. Registers organized by phase. See BVTHD. 0x00000000 R/W
0x69D BITHD_2 SPI burst read accessible. Registers organized by phase. See BITHD. 0x00000000 R/W
0x69E BFWAT T_2 SPI burst read accessible. Registers organized by phase. See BFWATT. 0x00000000 R/W
0x69F BFVA_2 SPI burst read accessible. Registers organized by phase. See BFVA. 0x00000000 R/W
0x6A0 BFIRMS_2 SPI burst read accessible. Registers organized by phase. See BFIRMS. 0x00000000 R/W
0x6A1
BFVRMS_2
SPI burst read accessible. Registers organized by phase. See BFVRMS.
0x00000000
R/W
0x6A2 BIRMSONE_2 SPI burst read accessible. Registers organized by phase. See BIRMSONE. 0x00000000 R/W
0x6A3 BVRMSONE_2 SPI burst read accessible. Registers organized by phase. See BVRMSONE. 0x00000000 R/W
0x6A4
BIRMS1012_2
SPI burst read accessible. Registers organized by phase. See BIRMS1012.
0x00000000
R/W
0x6A5 BVRMS1012_2 SPI burst read accessible. Registers organized by phase. See BVRMS1012. 0x00000000 R/W
0x6A6 CV_PCF_2 SPI burst read accessible. Registers organized by phase. See CV_PCF. 0x00000000 R/W
0x6A7 CI_PCF_2 SPI burst read accessible. Registers organized by phase. See CI_PCF. 0x00000000 R/W
0x6A8 CIRMS_2 SPI burst read accessible. Registers organized by phase. See CIRMS. 0x00000000 R/W
0x6A9 CVRMS_2 SPI burst read accessible. Registers organized by phase. See CVRMS. 0x00000000 R/W
0x6AA CWAT T_2 SPI burst read accessible. Registers organized by phase. See CWATT. 0x00000000 R/W
0x6AB CVA_2 SPI burst read accessible. Registers organized by phase. See CVA. 0x00000000 R/W
0x6AC CVAR_2 SPI burst read accessible. Registers organized by phase. See CVAR. 0x00000000 R/W
0x6AD CFVAR_2 SPI burst read accessible. Registers organized by phase. See CFVAR. 0x00000000 R/W
0x6AE
CPF_2
SPI burst read accessible. Registers organized by phase. See CPF.
0x00000000
R/W
0x6AF CVTHD_2 SPI burst read accessible. Registers organized by phase. See CVTHD. 0x00000000 R/W
0x6B0 CITHD_2 SPI burst read accessible. Registers organized by phase. See CITHD. 0x00000000 R/W
0x6B1 CFWATT_2 SPI burst read accessible. Registers organized by phase. See CFWATT. 0x00000000 R/W
0x6B2 CFVA_2 SPI burst read accessible. Registers organized by phase. See CFVA. 0x00000000 R/W
0x6B3 CFIRMS_2 SPI burst read accessible. Registers organized by phase. See CFIRMS. 0x00000000 R/W
0x6B4 CFVRMS_2 SPI burst read accessible. Registers organized by phase. See CFVRMS. 0x00000000 R/W
0x6B5 CIRMSONE_2 SPI burst read accessible. Registers organized by phase. See CIRMSONE. 0x00000000 R/W
0x6B6 CVRMSONE_2 SPI burst read accessible. Registers organized by phase. See CVRMSONE. 0x00000000 R/W
0x6B7
CIRMS1012_2
SPI burst read accessible. Registers organized by phase. See CIRMS1012.
0x00000000
R/W
