Figure 3-2: Switch Locations

Reset Pushbutton ( SW1 )

The reset pushbutton resets the ADAU1452 SigmaDSP. Reset ( LED4 ) is used to indicate when the board is in

reset.

Connectors

This section describes connector functionality and provides information about mating connectors. The connector

locations are shown in the Connector Locations figure.

Switches

EVAL-AD2428WD1BZ A

B Evaluation Board Manual

3–3
