Analog Devices EVAL-AD2428WD1BZ User Manual

The ADP621 CLK jumper is used to select the routing of the ADP621 CLK signal. The default setting for the
jumper is pin 1.
Jumper Clock Routing
3 and 4 AD2428_BCLK
1 and 3 AD2428_IO7
3 and 5 ADAU1452_BCLK_OUT0
NTC ( JP12 )
Input to the Thermistor Monitoring Circuits. The NTC pin connects to a battery’s thermistor to determine if the
battery is too hot or too cold to charge. If the battery’s temperature is out of range, charging is paused until it re-
enters the valid range. A low drift bias resistor is required from VIN to NTC and a thermistor is required from NTC
to ground. If the NTC function is not desired, the NTC pin should be grounded This jumper is installed by default.
A
2
B REG ( JP13 )
The A
2
B REG jumper is used to enable or disable the regulator for the AD2428 transceiver. The default setting for
the jumper is not installed.
Jumper
Clock Routing
Installed Regulator Disabled
Not Installed Regulator Enabled
A
2
B Voltage ( JP14 )
The A
2
B Voltage jumper is used to select the voltage for the AD2428 transceiver. The default setting for the jumper
is installed.
Jumper
Clock Routing
Installed 7V
Not Installed 8V
ADAU1761 MCLK Select ( JP19 )
The ADAU1761 MCLK Select jumper is used to select the MCLK source for the ADAU1761 SigmaDSP, and the
default position is 1 and 2. This jumper is available on Rev 1.1 boards and later, and earlier versions may label this
jumper as ADAU1961 MCLK Select. As the ADAU1761 is pin-compatible with the ADAU1961, the footprint and
silkscreen are identical in this regard.
Jumpers
3–18
EVAL-AD2428WD1BZ A
2
B Evaluation Board Manual
