DRX0 ( JP7 )
The DRX0 jumper is used to select the routing of the AD2428 DRX0 signal. The default setting for the jumper is
pins 3 and 4.
Jumper Clock Routing
3 and 4 ADAU1452_SDATA_OUT0
1 and 3 ADAU1761_ADC
3 and 5 ADMP621_DATA0
DRX1 ( JP8 )
The DRX1 jumper is used to select the routing of the AD2428 DRX1 signal. The default setting for the jumper is
pins 2 and 3.
Jumper Clock Routing
1 and 2 ADMP621_DATA1
2 and 3 ADAU1452_SDATA_OUT1
DTX1 ( JP9 )
The DTX1 jumper is used to select the routing of the AD2428 DTX1 signal. The default setting for the jumper is
pins 3 and 4.
Jumper
Clock Routing
3 and 4 ADAU1452_SDATA_IN1
1 and 3 ADAU1452_SDATA_OUT1
3 and 5 ADAU1761_ADC
DTX0 ( JP10 )
The DTX0 jumper is used to select the routing of the AD2428 DTX0 signal. The default setting for the jumper is
pins 1 and 2.
Jumper
Clock Routing
1 and 2 ADAU1452_SDATA_IN0
2 and 3 ADAU1761_DAC
ADP621 CLK ( JP11 )
Jumpers
EVAL-AD2428WD1BZ A
2
B Evaluation Board Manual
3–17
