Part Description Manufacturer Part Number
2-pin DuraClik Molex 5023520200
Mating Cable
DuraClik cable assembly
Power Plug ( P4 )
This powers up the board with a 12V supply. Power is required when the board is operating in both master and slave
mode.
Part Description Manufacturer Part Number
2.1 mm power jack CUI PJ-102AH
Mating Cable
12.0VDC@1.5A power supply CUI EMSA120150-P5RP-SZ
Power Terminal ( P5 )
This powers up the board with a 12V supply. Power is required when the board is operating in both master and slave
mode.
Part Description
Manufacturer Part Number
5.08mm power jack Weidmuller 1760510000
Mating Cable
12.0VDC discrete wires
Battery ( P6 )
The battery connector is a terminal block for connecting to a 3.7V Li-Ion battery. This battery from adafruit was
tested on the board.
Jumpers
This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper
locations.
Connectors
3–6
EVAL-AD2428WD1BZ A
2
B Evaluation Board Manual
