Figure 3-3: Connector Locations

SPDIF Input ( J1 )

The SPDIF Input connector is conencted to the SPDIFIN on the ADAU1452 - SigmaDSP Digital Audio Process-

or.

Part Description

Manufacturer Part Number

Fiber optic receiver Everlight PLR135/T10

Mating Cable

Connectors

3–4

EVAL-AD2428WD1BZ A

B Evaluation Board Manual
