Jumper Clock Routing
1 and 2 ADAU1452_CLKOUT
2 and 3 AD2428_BCLK
LEDs
This section describes the on-board LEDs. The LED Locations figure shows the LED locations.
Figure 3-13: LED Locations
A
2
B Interrupt ( LED1 )
LEDs
EVAL-AD2428WD1BZ A
2
B Evaluation Board Manual
3–19
