Table 6. Output File Descriptions
File Name Contents
metadata.csv Values from the datapath and FFT settings
waveforms.csv Captured codes on each channel and STATUSx and
auxiliary register values vs. time in seconds
ffts.csv Calculated FFT values in dB vs. frequency in Hz
metrics.csv Values in FFT metrics table
