4.10 HDCP management
Keys’ checking is performed according to the most restricve condion among the 2 following ones:
- Every 2 seconds
- Every 128 frames
HDCP protected content can be displayed only on HDCP protected outputs or displays. Therefore, whenever
an HDCP protected source is placed into a layer routed to a non-protected output, the QuickMatriX will not
output the protected content on this non-protected output, and the layer will be grayed.
If possible, the QuickMatriX will allow to display all other non-protected contents, otherwise the enre
output will be muted unl the protected content is no longer routed.
The HDCP negoaon can be enabled or disabled on all HDCP inputs.
The HDCP negoaon can be enabled or disabled on all HDCP outputs.
The QuickMatriX can manage HDCP repeaters on its outputs: up to 32 display devices can authencate
simultaneously on each output.
In order to permit quick idencaon of all the HDCP operaons on the device, the QuickMatriX provides a
full set of status summary to help the user with the HDCP management:
- A front panel menu that displays all the general HDCP status of all inputs and outputs
4.10.6 Status
Class
HDCP Receiver Yes
HDCP Transmier Yes
HDCP Repeater No
HDCP Receiver
The input HDCP detecon is managed by the input components according to HDCP specicaon.
The QuickMatriX manages the output HDCP detecon according to one of the following criteria:
- Hot plug,
- 3-second period aempt.
4.10
