5.1.1 Rear panel - Ref. QMX150
1.  100-240 VAC 2.5A 50/60HZ / FUSE F4A 250 VAC; internal, autoswitchable; 110W
2. : inputs #1 to #2
3.  audio inputs #1 to #2
4.  for audio inputs (balanced) #1 to #4
5.  for audio outputs (balanced) #1 to #2
6.  audio outputs #1 to #2
7.  inputs #1 to #4
8.  DVI-D inputs #1 to #4. Capability to receive digital audio signal from HDMI connector via
an adaptor (HDMI-compable)
9. 
10.  HDMI inputs #3 to #6. Digital audio compliant
 communicaon port with DB9 female connector
 HD15 outputs #1 to #2
  DVI-I outputs #1 to #2. Capability to transmit digital audio signal towards a HDMI
connector via an adaptor (HDMI-compable)
5. CONNECTING THE QUICKMATRIX
5.1 

1 2 3
4 5
6
8 9
11
7
10
1312
