Anderson WRAPTOR User Manual

Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0
Toll Free : 1-888-833-2952, Tel. : 819-382-2952, Fax. : 819-382-2643 Email : service@granderson.com
PARTS LIST
DESCRIPTIONPARTQTYITEM
STEERING AXLE22507911
RIGHT HOOP REINFORCMENT
22508012
LEFT HOOP REINFORCMENT22508113
REAR REINFORCMENT UPPER SECTION22508214
RIGHT SIDE FRAME2250831
5
LEFT SIDE FRAME
22508416
SPEAR SUPPORT
22508527
RIGHT HOOP SUPPORT22508628
LEFT HOOP SUPPORT22508729
HOOP AND SPEAR SUPPORT
225088110
RIGHT BALE GUIDE
225089211
LEFT BALE GUIDE225090412
CARRIAGE BOLT5004421213
RIGHT BALE GUIDE SUPPORT
225091214
LEFT BALE GUIDE SUPPORT
225092115
REAR REINFORCMENT BOTTOM SECTION225093116
LEFT BOTTOM FRAME225094217
RIGHT BOTTOM FRAME
225095218
HOOP DRIVE WHEEL
225096119
6 - REAR FRAME
P. 9
13
3
15
6
5
16
1
4
17
18
19
2
14
12
11
9
7
10
8
