Anderson WRAPTOR - Page 51

DETAIL B
Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0
Toll Free : 1-888-833-2952, Tel. : 819-382-2952, Fax. : 819-382-2643 Email : service@granderson.com
B
PARTS LIST
DESCRIPTIONPARTQTYITEM
HUB21062811
TIRE48150422
WASHER21062913
WASHER21063014
BRAKE SUPPORT
22509915
DRIVE WHEEL BRAKE210634-116
SPRING3040011
7
CARRIAGE BOLT50050048
FLANGE NUT
50102449
BOLT
500004110
CARRIAGE BOLT500501611
NYLON NUT501034812
MOTOR SUPPORT
210719-1113
WHEEL SPRING
304013114
HYDRAULIQUE FITTING451097115
HYDRAULIQUE FITTING450712116
CHECK VALVE465878117
HYDRAULIC MOTOR
469032118
FLANGE BOLT500602
4
19
HYDRAULIQUE FITTING451173120
RIM481706121
TIRE AND RIM481505122
9- HOOP DRIVE WHEEL
P. 12
11
12
4
1
20
11
6
7
19
17
15
16
2
8
5
3
10
9
13
14
18
21
22
