DETAIL B
Anderson Equipment, 5125 de la Plaisance Chesterville (Québec) G0P 1J0
Email :
service@anderson-equipment.com
LISTE DE PIÈCES
DESCRIPTION
PIÈCEQTÉ
ITEM
HOOP SECTION, STRETCHER FRAME 210580-121
HOOP SECTION, STRETCHER FRAME-1210581-122
CARRIAGE BOLT
50044283
FLANGE NUT
50102284
B
1
2
1
2
13 - OUTSIDE HOOP
3
4
P. 21
