ANTI-TIP DEVICE INSTALLATION INSTRUCTIONS
NOTE: A risk of range tip over exists if the appliance is not installed in
accordance with the installation instructions provided. The proper use of this
device minimises the risk of TIP-OVER . In using this device the consumer
must still observe the safety precautions as stated in the Instruction Manual
and avoid using the oven door and/or lower drawer as a step stool.
Installation instructions are provided for wood and cement wall. Any other
type of construction may require special installation techniques as deemed
necessary to provide adequate fastening of the ANTI-TIP bracket to the wall.
STEP 1 – Locating The Bracket (see fig. 11)
A. Mark the wall where either the right or left rear “EDGE” of the range is to
be located.
B. Place the Anti-Tip Bracket 520mm for AXC1200FWT Range from the
marked “EDGE” toward centre of opening and against the back wall with a
first hole height of 45mm plus “A” (distance between side wall bottom
edge and floor after range levelling) as shown in figure 11.
C. Use the bracket as a template and mark the required holes, as shown in
figure 11, for the type of construction you will be using.
STEP 2 – Anti-Tip Bracket Installation
Locate the centre of the two holes to be drilled on the wall. Drill a 1/8” pilot
hole in the centre of each hole. (A nail or awl may be used if a drill is not
available). On Wood Construction Wall secure the Anti-Tip bracket to the wall
with the two self-drilling screws provided, and on Cement or Concrete
Construction Wall secure the Anti-Tip bracket to the wall by drilling two holes
with a 3/8” drilling bit and using the two 3/8” x 1 ½” wall plugs with screw.
NOTE: Be aware of not drilling the wall hole in proximity of pipes, electric
cables or other components inside the wall that may be damaged. As shown
in figure 11 you have two slots in the rear cover to choose from. Also, use a
minimum of 2 screws to install bracket to the wall.
