Hardware Installation

12 Andover Controls Corporation

Caution

Never drill holes in the ACX 780/781 cover or boards. A metal shaving

could easily short circuit the electronics.

2. Position two standard No. 8 screws for the precut eyelets in the

cabinet or backplate, and hang the cabinet or backplate on the

screws.

Figure 2 shows the location of various parts inside the ACX 780/781,

labeled on the cover plate. Note the parts of the controller labeled here.

You may want to refer to this figure to locate parts during the

installation process.
