26 CMX 240 Series Installation Guide
Figure 10. Communication Status Lights for Comm1
The first light is yellow, the second green, the third red. The lights to the
right of COMM1 indicate communication activity through the COMM1
port. The lights to the right of COMM2 indicate communication activity
through the COMM2 port. The different colored lights flash to indicate
the following:
TD (Yellow)—Flashes when the communication port is transmitting
data.
RD (Green)—Flashes when the custom port is receiving data.
RTS (Red)—Lights up to indicate equipment (modem, terminal,
printer) is on-line.
Infinet Status Lights
There are two Infinet status lights to the right of the Infinet connection.
Figure 11 shows how the lights appear for Infinet.
Figure 11. Communication Status Lights for Infinet
The different colored lights flash to indicate the following:
TD (Yellow)—Flashes when the Infinet is transmitting data.
RD (Green)—Flashes when the Infinet is receiving data.
RD
TD
RTS
COMM 1
(Green)
(Yellow)
(Red)
RD
TD
INFINET
(Green)
(Yellow)
