44
Installation Procedures
Subreflector Strut
Assembly
Step 1
Attach subreflector strut assemblies to 170147 quadrapod plates as shown in Figures
56 and 57. Tighten hardware until snug only.
• Use 1/2 x 1-1/2 in (38 mm) bolts, lockwashers and nuts
Figure 56
