3. FUNCTIONAL DESCRIPTION
3.1. GENERAL
The MRx18 is a repeater operating in the respective frequency range (e.g. MR918 –
900 MHz frequency range). The operation principle is depicted in the following block
diagram:
E0783B9
figure 3-1 Block diagram
