5.5.1. Settings - Radio Frequency

figure 5-5 Settings – Radio Frequency, exemplary

figure 5-6 Settings - Radio Frequency, high-contrast page

Radio Frequency

Parameter Description of Power

Band

For the single band repeater MRx18 only one band is displayed.

Power

To power on, check "Power ON Band MRx18"

Uncheck "Power ON Band MRx18" to power down the RF-section of the

repeater. If the RF section is powered down the band is not visible in the

Settings page. Alarms and Status information are not captured in the Status

page.
