User’s Manual for
MRx18 Rel. 2 Single-Band
Page 16 M0139ADD.doc
3.2. DESIGN AND CONNECTORS
figure 3-2 Connectors of MRx18
Donor antenna
connector RF BTS
DC connector
Modem connector
DC + Data
Ethernet
Coverage antenna
connector
connector
RF mobile
Reset and
installation assistance
switch
Connector modem RF
