User’s Manual for
MRx18 Rel. 2 Single-Band
Page 32 M0139ADD.doc
Modem Control
Parameter Description of Value
Modem Type
Different modems can be selected for SMS remote monitoring. If a
modem is connected to the repeater, it is automatically initialized during
the boot process of the repeater. If no reboot is performed, the modem
type has to be selected manually.
Software
Version
The software version of the modem connected to the repeater is shown.
If no modem is connected or the modem cannot be recognized the
message "no valid modem found" appears.
SMSC
The Service Center Phone Number (SMSC) is entered here. If the
SMSC is stored to the SIM card of the modem, no entry needs to be
done.
Destination
Phone Number
Both the number of the destination for alarm messages and heartbeat
SMS and the sender for SMS are determined herein. The number
should be preceded with a ‘+’. Only decimal digits are allowed, no
spaces.
Unit Location
The Unit Location is sent with each SMS to get information about e.g.
address location or building where the repeater is installed. No
validation is done with the entry. The Unit Location is a user-defined
field. The content of Unit Location on the Modem Control page
corresponds to that of the Unit Location on LAN Connectivity page. The
settings are only applied in the status bar at the bottom of each page
after a new login. Maximum 20 characters are allowed.
Unit ID
For identification the Unit ID is sent with each SMS. No validation is
done with the entry, it is recommended to use the serial number of the
repeater as Unit ID. Moreover, 20 characters are allowed.
Heartbeat
Interval
A heartbeat SMS is sent after a certain period of time that can be
selected in this field. The heartbeat indicates that the supervision of the
repeater is working. If no heartbeat message is sent after the interval
entered, the connection and supervision is down. If heartbeat interval is
set to "0", the heartbeat functionality is disabled.
Time to Next
Heartbeat
Depending on the heartbeat interval the time that still remains until the
next heartbeat will be sent to the destination phone number is indicated.
Alarming via
SMS
The alarming via SMS can be disabled in case no alarm and heartbeat
SMS shall be sent to the destination phone number.
However, settings can be changed or the status of the repeater can be
queried via SMS, when Alarming via SMS is disabled.
Confirm changes made by clicking the button.
