User’s Manual for
MRx18 Rel. 2 Single-Band
Page 38 M0139ADD.doc
Maintenance
Parameter Description of Modem Debugging
Location Area
Code
The Location Area Code of the existing server cell is indicated. This
information is provided by the connected modem. “No network” is stated
in case no modem is connected or is recognized to/by the repeater or
the modem is not able to access to a mobile network.
MCC / MNC
The Mobile Country Code (MCC) and Mobile Network Code (MNC) of
the server cell is indicated. The first three digits show the MCC, the last
two digits the MNC. The MCC and MNC are detected by the connected
modem. “No network” is stated in case no modem is connected or is
recognized to/by the repeater or the modem is not able to access to a
mobile network.
Cell Information
The cell information displays the ID of the cell the modem is served. “No
network” is stated in case no modem is connected or is recognized to/by
the repeater or the modem is not able to access to a mobile network.
RSSI (dBm)
The received signal level at the antenna port of the modem is displayed.
The loss of the modem coupler integrated in the repeater is considered.
“No network” is stated in case no modem is connected or is recognized
to/by the repeater or the modem is not able to access to a mobile
network.
Software
Version
The software version of the modem connected to the repeater is shown.
If no modem is connected or the modem cannot be recognized, the
message "no valid modem found" appears.
Maintenance
Parameter Description of Software Update
Guide for Windows
The procedure how to update the repeater software update herein.
For software update, please also refer to chapter 5.8 Upload new software version.
