7.2 Permissible branch loads
• In reference to mounting arrangement E
Nominal width
[mm]
200 250 300 350 400 500
Discharge branch
Forces
[N]
F
1
x
2400 3000 3600 4200 4800 6000
F
1
y
2150 2700 3200 3750 4300 5400
F
1
z
2700 3350 4000 4650 5300 6650
ΣF
1
4200 5200 6250 7300 8300 10450
Torque
[Nm]
M
1
x
1300 1800 2400 3100 3900 5800
M
1
y
900 1250 1700 2200 2750 4100
M
1
z
1000 1450 2000 2550 3200 4700
ΣM
1
1900 2600 3550 4550 5700 8500
Suction branch
Forces
[N]
F
2
x
2700 3350 4000 4650 5300 6650
F
2
y
2400 3000 3600 4200 4800 6000
F
2
z
2150 2700 3200 3750 4300 5400
ΣF
2
4200 5200 6250 7300 8300 10450
Torque
[Nm]
M
2
x
1300 1800 2400 3100 3900 5800
M
2
y
900 1250 1700 2200 2750 4100
M
2
z
1000 1450 2000 2550 3200 4700
ΣM
2
1900 2600 3550 4550 5700 8500
Table 5: maximum admissible branch loads
Sketch showing branch loads
F
1
z
F
2
z
F
1
y
F
2
y
F
2
x
F
1
x
M
1
z
M
2
z
M
1
y
M
2
y
M
2
x
M
1
x
