Series SD 39
28
7.3 Parts list
VDMA No. Description VDMA No. Description
102 volute casing 524.2 shaft sleeve
161 seal housing 524.3 shaft sleeve
161.2 seal housing 554 washer
161.3 seal housing 562 dowel pin
164 inspection cover 639 oil level indicator (optional extra)
183 support foot 642 oil sight
210 shaft 647 grease controller
230 impeller 647.1 grease controller
321 grooved ball bearing 672 oil fill/Vent plug
321.1 grooved ball bearing 685 safety washer
330 bearing housing 901.1 hex. nut
344 lanterned distance piece 901.2 hex. nut
360 bearing cover 902.1 stud
400.1 gasket 902.2 stud
400.2 gasket 902.3 stud
400.3 gasket 902.4 stud
400.4 gasket 903 drain plug with washer
410 seal ring 906 impeller lock screw
412 o-Ring 916.1 drain plug
412.1 o-Ring 916.2 drain plug
421 lip-seal 916.3 drain plug
433 mechanical seal 916.4 drain plug
452 gland 920.1 hex. nut
457 neck ring 920.2 hex. nut
459 lantern ring 920.3 hex. nut
461 gland packing 920.4 hex. nut
471 seal cover plate 930 safety stud
502.1 wearing ring 932 inner circlip
502.2 wearing ring 932.1 inner circlip
502.3 wearing ring 940.1 key
507 water thrower 940.2 key
524 shaft sleeve 940.3 key
524.1 shaft sleeve
