Animo OptiBean - Filling Ingredient Canisters

2011/04 31 EN
OptiBean
5.8 Filling the bean canister
1 If required, unlock the cover of the bean canister.
2 Remove the cover (A).
3 Fill the bean canister.
4 First put the beans in the small section and then in the large
section of the bean canister.
5 Replace the cover (A).
6 If required, lock the cover of the bean canister.
5.9 Filling the instant canisters
1 Open the machine door.
2 Turn the canister’s outlet upwards (A).
3 Lift the canister from the socket and pull it out from the rotor
(B).
4 Remove the cover (C).
5 Fill the instant canister. Make sure that you do not overfill the
instant canister.
6 Replace the cover.
7 Replace the canister into the socket.
8 Make sure the canister locks into place with the pin in the
hole.
9 Turn the canister’s outlet downwards (A).
10 Close the machine door.
A
C
B
A
C
A
