Animo OptiBean - Outlet Assembly Cleaning

2011/04 39 EN
OptiBean
6.2.13 Cleaning the outlet
1 Open the machine door.
2 Remove the outlet front (A) while holding the tab at the back
of the front.
3 Take out the outlet housing (B).
4 Clean the outlet housing.
5 Replace the outlet housing.
6 Replace the outlet front.
7 Take out the splitter (C) and drink outlet (D) from the front
piece of the outlet arm (E).
A
B
C
E
D
