anko MT-600 - Robot Right Side View; Charging Dock Components

Page 11 of 36
4.2 Robot Right Side View
4.3 Charging Dock
20 On / Off Switch 21 Direct Charging Port
22 Brush / Hair Cutter Storage Recess 25 Positive Charging Terminal
23 Power Indicator Light 26 Negative Charging Terminal
24 Battery Charger Jack 27 IR Sensor Window
20
25
26
27
24
23
21
22
