Anolis ArcPower 384 - Page 14

14
Mode/Channel
Value Function Type of control
1 2 3 4 5 6
9 11 11 3 3 15
0-255
Blue LED 3
Blue LED saturation control (0-100%) proportional
- 12 12 - 4 16
0-255
White LED 3
White LED saturation control (0-100%) proportional
- - - - - 17
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Zone 3 colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
- - - - - 18
0-255
Dimmer 3
Dimmer intensity from 0% to 100% proportional
ZONE 4
10 13 13 1 1 19
0-255
Red LED 4
Red LED saturation control (0-100%) proportional
11 14 14 2 2 20
0-255
Green LED 4
Green LED saturation control (0-100%) proportional
12 15 15 3 3 21
0-255
Blue LED 4
Blue LED saturation control (0-100%) proportional
- 16 16 - 4 22
0-255
White LED 4
White LED saturation control (0-100%) proportional
- - - - - 23
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Zone 4 colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
- - - - - 24
0-255
Dimmer 4
Dimmer intensity from 0% to 100% proportional
ZONE 5
13 17 17 1 1 25
0-255
Red LED 5
Red LED saturation control (0-100%) proportional
14 18 18 2 2 26
0-255
Green LED 5
Green LED saturation control (0-100%) proportional
15 19 19 3 3 27
0-255
Blue LED 5
Blue LED saturation control (0-100%) proportional
- 20 20 - 4 28
0-255
White LED 5
White LED saturation control (0-100%) proportional
