Anolis ArcPower 384 - Page 15

15
Mode/Channel
Value Function Type of control
1 2 3 4 5 6
- - - - - 29
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Zone 5 colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
- - - - - 30
0-255
Dimmer 5
Dimmer intensity from 0% to 100% proportional
ZONE 6
16 21 21 1 1 31
0-255
Red LED 6
Red LED saturation control (0-100%) proportional
17 22 22 2 2 32
0-255
Green LED 6
Green LED saturation control (0-100%) proportional
18 23 23 3 3 33
0-255
Blue LED 6
Blue LED saturation control (0-100%) proportional
- 24 24 - 4 34
0-255
White LED 6
White LED saturation control (0-100%) proportional
- - - - - 35
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Zone 6 colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
- - - - - 36
0-255
Dimmer 6
Dimmer intensity from 0% to 100% proportional
ZONE 7
19 25 25 1 1 37
0-255
Red LED 7
Red LED saturation control (0-100%) proportional
20 26 26 2 2 38
0-255
Green LED 7
Green LED saturation control (0-100%) proportional
21 27 27 3 3 39
0-255
Blue LED 7
Blue LED saturation control (0-100%) proportional
28 28 - 4 40
0-255
White LED 7
White LED saturation control (0-100%) proportional
