16
Mode/Channel
Value Function Type of control
1 2 3 4 5 6
- - - - - 41
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Zone 7 colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
- - - - - 42
0-255
Dimmer 7
Dimmer intensity from 0% to 100% proportional
ZONE 8
22 29 29 1 1 43
0-255
Red LED 8
Red LED saturation control (0-100%) proportional
23 30 30 2 2 44
0-255
Green LED 8
Green LED saturation control (0-100%) proportional
24 31 31 3 3 45
0-255
Blue LED 8
Blue LED saturation control (0-100%) proportional
- 32 32 - 4 46
0-255
White LED 8
White LED saturation control (0-100%) proportional
- - - - - 47
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Zone 8 colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
- - - - - 48
0-255
Dimmer 8
Dimmer intensity from 0% to 100% proportional
Common channels for all Zones
- - 33 - 49
0
1-15
16
17-55
56
57-95
96
97-134
135
136-174
Colour macros selection
No function
White tones
Blue=full, Red+Green+White=0
Red=0, Green-->up,Blue =full, White=0
Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue-->down, White=0
Red=0, Green=full, Blue =0, White=0
Red-->up, Green=full, Blue=0, White=0
Red=full, Green=full, Blue=0, White=0
Red=full, Green-->down, Blue=0, White=0
Red=full, Green=0, Blue=0, White=0
Red=full, Green=0, Blue-->up, White=0
Red=full, Green=0, Blue=full, White=0
Red-->down, Green=0, Blue=full, White=0
Red=0, Green=0, Blue=full, White=0
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
