Appendix Initialization
Item
Initial Value
by the [Preset] Key
Initial Value by the [Preset] + Power ON
(Setting Status at the Factory Shipment)
Pattern Generator output ON/OFF
Data pattern
Delivery mode
Send rate
Output method
DEF1 pattern name
DEF2 pattern name
DEF3 pattern name
DEF4 pattern name
DEF1 First delivery address
DEF2 First delivery address
DEF3 First delivery address
DEF4 First delivery address
IDLE First delivery address
DEF1 data bit length
DEF2 data bit length
DEF3 data bit length
DEF4 data bit length
IDLE data bit length
DEF1 pattern data
DEF2 pattern data
DEF3 pattern data
DEF4 pattern data
IDLE pattern data
OFF*
Definde: 1*
Single*
1200 bps*
1 bit NRZ*
Not changed nor erased
00000*
8*
Not changed nor erased
OFF
Definde: 1
Single
1200 bps
1 bit NRZ
Erased
00000
8
Erased
NOTE:
*: According to the preset memory content as changed.
