Section 1 Overview
1.1 Product Overview
Pattern Generator is an optional device of the MG3641A/MG3642A Synthesized Signal Generator. It has four free
pattern memories into which data can be written via GPIB by using a personal computer and a fixed pattern memory that
generates PN9 and PN15 pseudo-random pattern and 0101-fixed pattern. It generates data patterns synchronized with the
internal clock generator frequency.
Besides, when no data pattern is delivered, the idle pattern can be delivered.
Various FSK modulated waves can be output by combining with the FSK encoder which is optionally built in MG3641A/
MG3642A. In addition, this Pattern Generator can be used as a modulated signal source of the optional built-in pulse
modulator.
1.2 Devices Configuration
The Pattern Generator configuration is as follows:
Table 1-1 Standard configuration
Item Model Name/Code Product Name
Number of
Item (s)
Main Unit
Attachments
MG3641A/MG3642A-23
Z0351A
W1389AE
Pattern Generator
Label
Operation Manual
1
1
1
1.2 Devices Configuration
