Anritsu MG3641A - Data Output Method

13
4.2 Data Output Method
Data output method is described in detail.
(1) 1-bit NRZ output method
Data are sequentially output starting from the specified first delivery address LSB for the specified data bit length taken
out from the Data 2
1
Output.
Address
D7
(MSB )
D6 D5 D4 D3 D2 D1
D0
(LSB)
65535
65534
65533
:
00004
00003
00002
00001
00000
::::::::
D0 D1 D2 D3 D4 D5 D6
1/Rate
Int Mod Cont
231
Data 2
1
Data 2
0
Clock
Fixed to “0”
4.2 Data Output Method
